i-ARM Configuration Design

Last Updated: 2024-12

Prepared By: i-ARM Devops Team;Vivek.B@infotechtion.com

Prepared For: Consumer Architects

STANDARDS

Naming Standards

The naming standards and guidelines for Azure resources followed by the i-ARM are described in this section. Following recommended naming conventions makes managing resources in the Azure environment easier, increases clarity, and makes resource grouping and recognizing them simpler.

Note: In Azure, there are several types of resources that must have globally unique names. These resources are typically part of services that need to be accessible worldwide, so the names are unique across all tenants in Azure.

Below is the list of I-ARM resources which should have unique name

• Azure Key Vault
• Azure Container Registry
• Azure SQL Database Server
• Azure App Service (Web Apps & Function Apps)
• Azure Storage Account

Azure Component	Standard
Application Registration	spn-<azureserviceabbr>-iarm-<purpose>-<env>
Resource Group Name	rg-iarm-<purpose>-<regionabbr>-<env>
Azure Services (Without Storage Accounts)	<azureserviceabbr>-iarm-<iarmmodule>-<regionabbr>-<env>
Azure Storage Account	<azureserviceabbr>iarm<iarmmodule><regionabbr><env> (This should always be less than 24 characters)
Security Groups	sg-<azureserviceabbr>-iarm-<purpose>-<env>
Virtual Machine	<azureserviceabbr><iarm><purpose><regionabbr><env> (This should always be less than 15 characters)
General Names	Must include iarm to clearly identify a dedicated use of iarm.

Acronyms

Acronym	Description
MS	Microsoft
SPN	Service Principal
WAPP	Web application
IARM	Infotechtion-ARM
UIDIRECTORYACCESS	User interface directory access
PRD	Production
FUNC	Function
APIAUTH	Application Programming Interface Authentication
GRAPHAPI	Graph API
DEVOPSCONN	Azure Devops Connection
MYDISPPA	My Disposal Power Automate
SPOACCESS	SharePoint Online Access
SQL	Structured Query Language
SG	Service Group
SVC	Service
VNET	Virtual Network
RG	Resource Group
WEBAPP	Web Application
FUNCAPP	Function Application
PE	Private Endpoint
KV	Key Vault
ASP	Active Server Pages
MYDISP	My Disposal (feature of iARM)
UI	User interface
VM	Virtual Machine
IAC	Infrastructure as a code
PRM	Physical Records Management
SPFx	SharePoint Framework
PnP	Patterns and Practices
PBI	Power BI
DG	Data Gateway
RDP	Remote Desktop
WJ	Web Job
ACI	Azure Container Instance
ACR	Azure Container Registry
AFS	Azure File Share
NFS	Network File Share
MPIP	Microsoft Purview Information Protection

Overview

Design Architecture

![A screenshot of a computer


Ref	Source Name	Target Name	Protocols	Data Gateway	VNet	Target’s Inbound Port	Firewall	Authentication method
	MS Purview – i-ARM Power Automate	i-ARM SQL Data store	TCP / HTTPS: <confirmed during implementation>	Y	Source: N Target: N	1433	Y –native	SQL Authentication
	i-ARM Function Apps	MS Purview	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Dedicated Service Principal (OAUTH)
	i-ARM Function Apps	i-ARM SQL Data store	TCP / HTTPS: <confirmed during implementation>	N	Source: Y Target: N	1433	Y –native	Entra Managed Identity (OAUTH)
	i-ARM Function Apps	Application Insights/Log Analytics	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Instrumentation Key
	i-ARM Function apps	SharePoint Online	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Dedicated Service Principal (OAUTH)
	i-ARM Power Automate	Key Vault	HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	Y –native	Entra Cloud Service Account
	i-ARM Power Automate	Storage Account	HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	Y –native	Entra Cloud Service Account
	i-ARM Power Automate	SharePoint Online	HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	N	Dedicated Service Principal (OAUTH)
	i-ARM Function Apps	Key Vault	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	Y –native	Entra Managed Identity (OAUTH)
	i-ARM WebApp (App Service)	i-ARM Function apps	HTTPS: <confirmed during implementation>	N	Source: Y Target: Y	443	N	Entra Managed Identity (OAUTH)
	i-ARM WebApp (App Service)	Graph APIs graph.microsoft.com/*	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Dedicated Service Principal (OAUTH)
	i-ARM Function Apps	Graph APIs graph.microsoft.com/*	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Dedicated Service Principal (OAUTH)
	i-ARM Web Job (App Service)	Graph APIs graph.microsoft.com/*	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Dedicated Service Principal (OAUTH)
	i-ARM Web Job (App Service)	i-ARM SQL Data store	TCP / HTTPS: <confirmed during implementation>	N	Source: Y Target: N	1433	Y –native	Entra Managed Identity (OAUTH)
	i-ARM Web Job (App Service)	Key Vault	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	Y –native	Entra Managed Identity (OAUTH)
	i-ARM Web Job (App Service)	Office Management API manage.office.com/api/*	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Dedicated Service Principal (OAUTH)
	i-ARM Function Apps	Office Management API manage.office.com/api/*	HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	N	Dedicated Service Principal (OAUTH)
	Infotechtion i-ARM DevOps	Resource Group	HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	N	Dedicated Service Principal (OAUTH)
	Power BI	i-ARM SQL Data store	TCP / HTTPS: <confirmed during implementation>	Y	Source: N Target: N	1433	Y –native	SQL Authentication
	Landing Zone i-ARM Container Registry	Infotechtion Container registry	TCP / HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	Y - native	Dedicated Service Principal (OAUTH)
	i-ARM Container Instance	Landing Zone i-ARM Container Registry	TCP / HTTPS: <confirmed during implementation>	N	Source: Y Target: N	443	Y - native	Entra Managed Identity (OAUTH)
	i-ARM Agent Services	Key Vault	HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	Y –native	Entra Cloud Service Account
	i-ARM Agent Services	i-ARM SQL Data store	TCP / HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	Y –native	Dedicated Service Principal (OAUTH)
	i-ARM Agent Services	Storage Account	HTTPS: <confirmed during implementation>	N	Source: N Target: N	443	Y –native	Entra Cloud Service Account
25	i-ARM Agent Services	Azure File Share and Network File Share	SMB	N	Source: N Target: N	445	Y –native (Storage Account)	Entra Cloud Service Account

Azure Governance

Management Group

This section describes the deployment strategy for the i-ARM solution within the Azure environment, specifically focusing on the use of Management Groups. By utilizing a structured approach to Management Groups, the solution can be efficiently organized and governed within the landing zone, ensuring compliance, security, and streamlined management of resources across multiple subscriptions.

Parent	Landing Zone
Management Group	<Consumer Landing Zone>
Azure Monitor	<Consumer log analytics workspace for app events>

Subscription

This section outlines the deployment of i-ARM solution within an existing or dedicated Azure subscription in the specified tenancy. All solution components are consolidated within a single Azure resource group, facilitating streamlined management and organization of resources.

Tenant	<Consumer tenant name> (<Consumer tenant id>)
Subscription	<Consumer subscription name>

Subscription Resource Providers

This section outlines the configuration of the required Azure subscription resource providers for deploying the i-ARM solution within the Azure subscription identified for i-ARM in the specified tenancy. All necessary resource providers are enabled at the subscription level, ensuring that all i-ARM solution components can be consolidated within a single Azure resource group. This setup facilitates streamlined management and organization of resources, allowing for consistent provisioning, monitoring, and scaling of the solution's components.

Before deploying the i-ARM solution, ensure that the following Azure resource providers are registered within the subscription by the subscription owner:

Ref	Resource Provider	Description
1	Microsoft.DomainRegistration	Manages domain registrations for custom domains in Azure.
2	Microsoft.Network	Provides networking capabilities, including Virtual Networks, Load Balancers, and Network Security.
3	Microsoft.Advisor	Delivers best practice recommendations for cost, security, reliability, and operational excellence.
4	Microsoft.CloudShell	Supports the Azure Cloud Shell service, a browser-accessible shell environment for managing resources.
5	Microsoft.Sql	Enables provisioning of Azure SQL databases and associated resources.
6	Microsoft.MarketplaceNotifications	Handles notifications related to Azure Marketplace subscriptions and services.
7	Microsoft.ServiceLinker	Facilitates connections between Azure services for resource linking and integrations.
8	Microsoft.ManagedIdentity	Provides Managed Identity for secure service connections without credentials.
9	Microsoft.AlertsManagement	Manages and monitors alerts for various Azure services.
10	Microsoft.RecoveryServices	Manages backup and recovery solutions using Azure Backup and Site Recovery.
11	Microsoft.Security	Manages security solutions and configurations within Azure Security Center.
12	Microsoft.Web	Enables hosting and management of web applications, including Azure App Services and Functions.
13	Microsoft.Storage	Manages Azure Storage accounts including Blob, File Shares, and more.
14	Microsoft.Compute	Provides virtual machines, scale sets, and compute-related resources.
15	Microsoft.EventGrid	Enables event-driven architectures with support for events from Azure resources.
16	Microsoft.OperationalInsights	Provides monitoring and management solutions like Log Analytics and Azure Monitor.
17	microsoft.insights	Enables Azure Monitor features for diagnostics, metrics, and alerts.
18	Microsoft.KeyVault	Manages secure storage and access for secrets, keys, and certificates.
19	Microsoft.ResourceHealth	Provides real-time monitoring of resource health and availability in Azure.
20	Microsoft.GuestConfiguration	Manages guest OS configuration policies and auditing in Azure Virtual Machines.
21	Microsoft.PolicyInsights	Manages policy compliance status and enforcement in Azure resources.
22	Microsoft.Logic	Facilitates workflows using Azure Logic Apps for integration and automation.
23	Microsoft.Automation	Provides automation capabilities for resource management through runbooks and scripts.
24	Microsoft.ContainerInstance	Manages Azure Container Instances (ACI), which allow you to run containers in a fully managed environment without the need for VM provisioning or container orchestration.
25	Microsoft.PowerPlatform	Manages resources related to Microsoft Power Platform, which includes Power Apps, Power Automate, Power BI, and Power Virtual Agents. This provider allows you to create, manage, and integrate Power Platform environments within Azure, enabling the development and deployment of low-code/no-code applications and automation workflows. It's essential for managing Power Platform environments, connections, and integrations with Azure resources.
26	Microsoft.ContainerRegistry	Manages Azure Container Registry (ACR), a managed Docker container registry service provided by Microsoft Azure. It allows you to store and manage Docker container images and artifacts.

Azure Policy

This section highlights the importance of Azure Policies in governing the i-ARM solution and ensuring compliance with organizational standards. This section is usually completed with the consumer architecture team, and refers to consumer specific policies as-built in consumer environment.

Entra

Application Registration

This section details the process and significance of Microsoft Entra / Azure Active Directory (AD) application registration for the i-ARM solution. Application registration is essential for enabling secure access and authentication for several components of the solution. By registering the application in Entra ID / Azure AD, you can manage permissions, control access to APIs, and ensure secure integration with other Azure services.

Note:

• All SPN permissions must have global admin consent to function properly.
• All Service Principal Names (SPNs) utilizing a client secret or certificate should have an expiration date set to a minimum of one year from the date of creation, unless explicitly specified otherwise.

Name	spn-wapp-iarm-uidirectoryaccess-prd
Description	The service principal used by the i-ARM webapp for hosting the Single-page portal to display the i-ARM user interface and authenticate users against MS Entra ID.
Single-page app	https://web-iarm-ui-regionabbr-prd.azurewebsites.net
Token configuration	Token type: ID Optional Claim: login_hint
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: Groupmember.Read.All	Delegate

Name	spn-func-iarm-apiauth-prd
Description	The service principal used for operations which relate to Azure function applications required for the functioning of the ‘My Data & My Disposal’ user interface people picker feature.
Web Redirect	https://func-iarm-mydata-regionabbr-prd.azurewebsites.net/.auth/login/aad/callback https://func-iarm-mydisp-regionabbr-prd.azurewebsites.net/.auth/login/aad/callback *Pointing to the function apps created
Expose an API	Scope	Authorized Client Applications
	Application ID Uri: api://{ Client ID (spn-func-iarm-apiauth-prd) }/user_impersonation Scope Name: user_impersonation Who can consent? Admins and Users Admin consent display name: user_impersonation Admin consent description: Access iarm apis State: Enabled	{ Client ID (spn-wapp-iarm-uidirectoryaccess-prd) }

Name	spn-func-iarm-urclabelsync-prd
Description	The service principal is used by the i-ARM URC function app to sync the retention labels from Microsoft Purview to i-ARM Data Store.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: RecordsManagement.ReadWrite.All	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientsecret
Certificates & Secrets	Client Secret: Create a client secret and capture the information in a secure place. This information will be stored in the key vault.

Name	spn-func-iarm-graphapi-prd
Description	The service principal necessary for executing Microsoft Graph API calls from other APIs.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: User.Read.All	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientcert
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-devopsconn-iarm-deploy-prd
Description	The service principal used for establishing the service connection from target environment to Infotechtion DevOps.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
RBAC	Scope	Role
rg-iarm-svc-regionabbr-prd	Contributor
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientsecret
Certificates & Secrets	Client Secret: Create a client secret and capture the information in a secure place. This information will be stored in the key vault.

Name	spn-func-iarm-notifications-prd
Description	The service principal required to send any i-ARM notifications to stakeholders.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: Mail.Send	Application
Microsoft Graph: User.ReadBasic.All	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientcert
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-mydisppa-iarm-spoaccess-prd
Description	The service principal used for operations which relate to the Power Automate Flows required for the “My Disposal” Module of i-ARM.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: Sites.ReadWrite.All	Application
SharePoint: Sites.Read.All	Application
SharePoint: Sites.FullControl.All	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientcert
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-func-iarm-mydispconnspoaccess-prd
Description	The service principal used for operations which relate to the M365 Audit Disposal Connector required for the “My Disposal” Module of i-ARM.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: Sites.Read.All	Application
Microsoft Graph: Files.Read.All	Delegate
Microsoft Graph: Files.Read.All	Application
SharePoint: Sites.Read.All	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientcert
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-sql-iarm-sqlaccess-prd
Description	The service principal used by i-ARM internal services to authenticate with i-ARM SQL leveraging SPN based Entra authentication. This can be changed to use a service account to align with consumer architecture standards.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
External Provider	CREATE USER [spn-sql-iarm-sqlaccess-prd] FROM EXTERNAL PROVIDER ALTER ROLE db_datareader ADD MEMBER [spn-sql-iarm-sqlaccess-prd] ALTER ROLE db_datawriter ADD MEMBER [spn-sql-iarm-sqlaccess-prd] GRANT EXEC TO [spn-sql-iarm-sqlaccess-prd] Note: A DB admin is required to login to SQL and run the above scripts
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientsecret
Certificates & Secrets	Client Secret: Create a client secret and capture the information in a secure place. This information will be stored in the key vault.

Name	spn-func-iarm-prmprovisioning-prd
Description	This service principal is used to provide access to specific SharePoint sites to the Sites.Selected permission for the “spn-func-iarm-prmbulkimport-prd”
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: Sites.FullControl.All	Application
SharePoint: Sites.FullControl.All	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientcert
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-func-iarm-prmbulkimport-prd
Description	This service principal is required to authenticate and communicate with SharePoint APIs for PRM Bulk Import functionality
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: TermStore.Read.All	Application
SharePoint: Sites.Selected	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientcert
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-func-iarm-prmsync-prd
Description	This service principal is required to authenticate and communicate with SharePoint APIs for PRM Sync functionality to i-ARM
API	Permission	Type
Microsoft Graph: User.Read	Delegate
SharePoint: TermStore.Read.All	Application
SharePoint: TermStore.ReadWrite.All	Application
SharePoint: Sites.Read.All	Application
SharePoint: Sites.ReadWrite.All	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientcert
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-wj-iarm-m365auditsync-prd
Description	This service principal is required for syncing M365 Audit Logs data to i-ARM Data Store
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Graph: AuditLog.Read.All	Application
Microsoft Graph: AuditLogsQuery-SharePoint.Read.All	Application
Microsoft Graph: AuditLogsQuery.Read.All	Application
Office 365 Management APIs: ActivityFeed.Read	Application
Office 365 Management APIs: ActivityFeed.ReadDlp	Application
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientsecret
Certificates & Secrets	Client Secret: Create a client secret and capture the information in a secure place. This information will be stored in the key vault.

Name	spn-agent-iarm-downloadarchiveblobs-prd
Description	The service principal used by the i-ARM agent for reading and downloading blobs stored in the archival storage account.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
RBAC	Scope	Role
kv-iarm-svc-regionabbr-prd	Key Vault Secrets User
kv-iarm-svc-regionabbr-prd	Key Vault Certificate User
saiarmarchiveregionabbrprd	Storage Blob Data Reader
Credentials	Key Vault	Secret Name
kv-iarm-svc-regionabbr-prd	{spn name}-clientid
kv-iarm-svc-regionabbr-prd	{spn name}-clientsecret
Certificates & Secrets	Client Secret: Create a client secret and capture the information in a secure place. This information will be stored in the key vault.

Name	spn-agent-iarm-scannerservice-prd
Description	The service principal used by the i-ARM Scanner agent to authenticate against KeyVault using the certificate installed on the VM.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
RBAC	Scope	Role
kv-iarm-svc-regionabbr-prd	Key Vault Secrets User
kv-iarm-svc-regionabbr-prd	Key Vault Certificate User
Certificates & Secrets	Certificates: Upload a certificate (public key) with one of the following file types: .cer, .pem

Name	spn-agent-iarm-mpipscannerservice-prd
Description	The service principal used by the MPIP Scanner agent to capture sensitive information on files based on the sensitive information types in Microsoft purview portal.
API	Permission	Type
Microsoft Graph: User.Read	Delegate
Microsoft Information Protection Sync Service: UnifiedPolicy.Tenant.Read	Application
Azure Rights Management Services: Content.DelegatedReader	Application
Azure Rights Management Services: Content.DelegatedWriter	Application
Certificates & Secrets	Client Secret: Create a client secret and capture the information in a secure place. This will be required while configuring the MPIP Scanner service on the Virtual Machine

Group

This part highlights the importance of Entra ID / Azure Active Directory security groups in controlling access and permissions within the i-ARM solution.

Name	sg-sub-iarm-reader-prd
Description	Read access to the azure subscription where i-ARM would be deployed.
RBAC	Scope	Role
Subscription	Reader
Members	<To be confirmed at the time of configuration>

Name	sg-svc-iarm-webappadministrators-prd
Description	i-ARM persona performing administrative actions within i-ARM.
RBAC	Scope	Role
NA
Members	<To be confirmed at the time of configuration>

Name	sg-svc-iarm-sqlentraadministrators-prd
Description	Entra ID administrators accessing i-ARM Data Store
RBAC	Scope	Role
NA
Members	<To be confirmed at the time of configuration>

Name	sg-svc-iarm-recordsadministrators-prd
Description	i-ARM Entra ID group required for the Records Administrator persona
RBAC	Scope	Role
NA
Members	<To be confirmed at the time of configuration>

Name	sg-svc-iarm-ediscoveryadministrators-prd
Description	i-ARM Entra ID group required for eDiscovery Administrator persona
RBAC	Scope	Role
NA
Members	<To be confirmed at the time of configuration>

Service/User Accounts

This part highlights the importance of Entra ID / Azure Active Directory service/user accounts in setting up and configuration of the i-ARM solution.

Name	To be Confirmed during engagement
Description	Account required for importing and configuring the power automate flows. This account should also be added as a Connection Creator in the data gateway Note: If the labels in the Microsoft Purview Compliance portal were created with an account different from the one importing the flow, the flows must be shared with the account that created the labels. Additionally, that account should have an E5 license along with the Power Automate Premium Per User Plan. If the Power Automate flows are imported into an environment other than the default Power Platform environment, the labels should only be created and managed using PowerShell. Learn more
License	E5 license with Power Automate Premium Per User Plan (Any plan that supports premium connectors)
Permissions	Scope	Role
Power Automate Environment	Environment Maker Role
	On-Premises Data Gateway (Power Platform Admin Center)	Connection Creator

Name	To be Confirmed during engagement
Description	Account identified as a Gateway Admin for the data gateway that is installed and configured
License	E5 license
Permissions	Scope	Role
Power Automate Environment	Environment Maker Role
	On-Premises Data Gateway (Power Platform Admin Center)	Gateway Admin

Name	To be Confirmed during engagement
Description	Account required to sync the label policies and labels from purview compliance portal. This account would be added to the custom role group created in purview compliance center
License	E5 license
Permissions	Scope	Role
Microsoft Purview Compliance Portal	Create a custom role group with the below roles in Microsoft Purview Compliance Center View-Only Retention Management View-Only Record Management

Name	To be Confirmed during engagement
Description	Account identified for publishing Power BI reports
License	E5 license
Permissions	Scope	Role
Power BI Workspace	Owner
Azure SQL Database	db_datareader

Name	To be Confirmed during engagement
Description	Account from which the notification emails would be sent
License	E3/E5
RBAC	Scope	Role
NA	NA

Name	To be Confirmed during engagement
Description	Account used by the windows service for reading and downloading blobs
License	E5 license
Permissions	Scope	Role
Azure Storage Account (saiarmarchiveregionabbrprd)	Storage Blob Data Reader
Azure Key Vault (kv-iarm-svc-regionabbr-prd)	* Key Vault Secrets User * Key Vault Certificate User

Name	To be Confirmed during engagement
Description	Account used by the windows service for scanning the Network File Shares or Azure File Shares
License	E5 license
Permissions	Scope	Role
Azure Storage Account (mounting must be done using the Storage Account access Key)	NA
Network File Share	Read Write access on the file share for scanning (Write is only necessary if Immutability Feature is enabled)
Azure Key Vault (kv-iarm-svc-regionabbr-prd)	* Key Vault Secrets User * Key Vault Certificate User

Name	To be Confirmed during engagement
Description	Account used by the MPIP Scanner service for installing and scanning the Network File Shares or Azure File Shares
License	E5 license
Other considerations	There should be at least one sensitivity label policy published to this service account for the MPIP Scanner to start capturing Sensitive information types. The sensitivity label should also have send to audit attribute set to true for the data to be captured in M365 audit logs. Reference: Enable Audit
Permissions	Scope	Role
sql-iarmmpip-svc-regionabbr-prd	Sysadmin Reference
sql-iarmmpip-svc-regionabbr-prd	db_owner
Network/ Azure File Share (Mounted on Scanner VM)	Read Write access on the file share for scanning (Write is only necessary if protection is being applied)
Azure Key Vault (kv-iarm-svc-regionabbr-prd)	* Key Vault Secrets User * Key Vault Certificate User

RBAC Roles

RBAC (Role-Based Access Control) on Azure is a system for managing access to Azure resources by assigning roles to different actors (users, groups, or managed identities)

Note: An authorized user from the consumer cloud team with an Owner role on the subscription is required to assign the necessary RBAC roles defined below for the following Azure services.

Service	Actor	Role	Actor Type	Azure Entra ID Group or Assignment Type
M365 and Azure	[Global Admin Account]	Global Admin	User	Direct
SharePoint Admin Portal	[SharePoint Administrator Account]	SharePoint Administrator	User	Direct
Microsoft Purview Portal	[Records Management Account]	Records Management (Purview Role group)	User	Direct
Azure Subscription Reader	sg-sub-iarm-reader-prd	Reader	Group	Entra ID Security Group
Azure Resource Group	spn-devopsconn-iarm-deploy-prd	Contributor	Service Principal	Direct
Azure Key Vault	sg-sub-iarm-reader-prd	Key Vault Secrets User	Group	Entra ID Security Group
Key Vault Certificate User	Group	Entra ID Security Group
spn-agent-iarm-downloadarchiveblobs-prd	Key Vault Secrets User	Service Principal	Direct
Key Vault Certificate User	Service Principal	Direct
spn-agent-iarm-scannerservice-prd	Key Vault Secrets User	Service Principal	Direct
Key Vault Certificate User	Service Principal	Direct
spn-devopsconn-iarm-deploy-prd	Key Vault Administrator	Service Principal	Direct
* func-iarm-urc-regionabbr-prd * func-iarm-mydisp-regionabbr-prd * func-iarm-mydata-regionabbr-prd * func-iarm-prmbulk-regionabbr-prd * func-iarm-prmsync-regionabbr-prd * wj-iarm-m365auditsync-regionabbr-prd * func-iarm-m365auditconnector-regionabbr-prd * func-iarm-m365dispconnector-regionabbr-prd	Key Vault Certificate User	Managed Identity	Direct
* func-iarm-urc-regionabbr-prd * func-iarm-mydisp-regionabbr-prd * func-iarm-mydata-regionabbr-prd * func-iarm-prmbulk-regionabbr-prd * func-iarm-prmsync-regionabbr-prd * wj-iarm-m365auditsync-regionabbr-prd * func-iarm-m365auditconnector-regionabbr-prd * func-iarm-m365dispconnector-regionabbr-prd	Key Vault Secrets User	Managed Identity	Direct
[Service Account Importing the PowerAutomate Flows]	Key Vault Certificate User	User	Direct
Key Vault Secrets User	User	Direct
[Service Account reading and downloading blobs]	Key Vault Certificate User	User	Direct
Key Vault Secrets User	User	Direct
Dataverse (Common Data Service)	Key Vault Secrets User	Enterprise Application	Direct
Azure SQL Database [sql-iarm-svc-regionabbr-prd]	* func-iarm-urc-regionabbr-prd * func-iarm-mydisp-regionabbr-prd * func-iarm-mydata-regionabbr-prd * func-iarm-prmbulk-regionabbr-prd * func-iarm-prmsync-regionabbr-prd * wj-iarm-m365auditsync-regionabbr-prd * func-iarm-m365auditconnector-regionabbr-prd * func-iarm-m365dispconnector-regionabbr-prd	db_datareader db_datawriter	Managed Identity	Direct
spn-sql-iarm-sqlaccess-prd	db_datareader db_datawriter	Service Principal	Direct
Azure SQL Database [sql-iarmmpip-svc-regionabbr-prd]	[Service Account identified for MPIP Scanner installation and configuration]	Sysadmin sb_owner	User	Direct
Azure Storage Account [saiarmprmbulkregionabbrprd]	func-iarm-prmbulk-regionabbr-prd	* Storage Blob Data Contributor * Storage Queue Data Contributor * Storage Table Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarmmydispregionabbrprd]	func-iarm-mydisp-regionabbr-prd	Storage Blob Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarmmydataregionabbrprd]	func-iarm-mydata-regionabbr-prd	Storage Blob Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarmurcregionabbrprd]	func-iarm-urc-regionabbr-prd	Storage Blob Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarmprmsyncregionabbrprd]	func-iarm-prmsync-regionabbr-prd	Storage Blob Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarm365syncregionabbrprd]	wj-iarm-m365auditsync-regionabbr-prd	* Storage Blob Data Contributor * Storage Queue Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarm365connregionabbrprd]	func-iarm-m365auditconnector-regionabbr-prd	Storage Blob Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarmdispconregionabbrprd]	func-iarm-m365dispconnector-regionabbr-prd	* Storage Blob Data Contributor * Storage Queue Data Contributor * Storage Table Data Contributor	Managed Identity	Direct
Azure Storage Account [saiarmarchiveregionabbrprd]	[Service Account importing the Power Automate Flows]	Storage Blob Data Contributor	User	Direct
[Service Account reading and downloading blobs]	Storage Blob Data Reader	User	Direct
[spn-agent-iarm-downloadarchiveblobs-prd]	Storage Blob Data Reader	Service Principal	Direct
Azure Storage Account [saiarmdiappregionabbrprd]	func-iarm-mydata-regionabbr-prd	Storage Blob Data Contributor	Managed Identity	Direct
Azure VM	sg-sub-iarm-reader-prd	Reader	Group	Entra ID Security Group
Azure Bastion	sg-sub-iarm-reader-prd	Reader	Group	Entra ID Security Group
Power Platform	[Service Account Importing the Power Automate Flows]	Environment Maker Role	User	Direct
[Service Account Importing the Power Automate Flows]	Connection Creator	User	Direct
[Service Account for Gateway Admin]	Gateway Admin	User	Direct
Power BI	[Service Account for Publishing Power BI Reports]	Power BI Workspace Owner	User	Direct
M365 Purview Compliance Portal	[Service Account for syncing label and label policies from Microsoft Purview Compliance Portal]	View-Only Retention Management View-Only Record Management	User	Direct
Azure Container Instance	User managed Identity (ADD Name)	ACR Role	User Managed Identity	Direct

Networking

Virtual Network

This section highlights that the relevant PaaS services for the i-ARM solution are deployed within the Azure Virtual Network. This deployment ensures secure communication and isolation among resources while leveraging the benefits of Azure networking capabilities.

Name	Resource Group	Region	Address Space	Description
vnet-iarm-svc-regionabbr-prd	rg-iarm-svc-regionabbr-prd	<Consumer Azure region>	x.x.x.x/22	A Virtual Network that is essential for securing communication among PaaS services, managing traffic, and ensuring compliance.

User Defined Route Tables

The i-arm solution currently operates using the default routing rules associated with the various provisioned subnets, without the implementation of custom routing. However, it is designed to be flexible and can be customized to utilize specific route tables as needed. This customization is particularly useful in scenarios involving a central firewall or when traffic needs to be directed towards a Network Virtual Appliance (NVA).

Name	Route Name	Address prefix	Next hope type	Next hope IP address	Attached Subnet
rt-iarm-webapp-regionabbr-prd	To-Internet	0.0.0.0/0	Virtual appliance	< Connectivity Subscription Firewall Private IP Address>	nsg-iarm-webapp-regionabbr-prd

Name	Route Name	Address prefix	Next hope type	Next hope IP address	Attached Subnet
rt-iarm-funcapp -regionabbr-prd	To-Internet	0.0.0.0/0	Virtual appliance	<Connectivity Subscription Firewall Private IP Address>	nsg-iarm-funcapp-regionabbr-prd

Name	Route Name	Address prefix	Next hope type	Next hope IP address	Attached Subnet
rt-iarm-pe -regionabbr-prd	To-Internet	0.0.0.0/0	Virtual appliance	< Connectivity Subscription Firewall Private IP Address>	nsg-iarm-pe-regionabbr-prd

Name	Route Name	Address prefix	Next hope type	Next hope IP address	Attached Subnet
rt-iarm-workloads-regionabbr-prd	To-Internet	0.0.0.0/0	Virtual appliance	< Connectivity Subscription Firewall Private IP Address>	nsg-iarm-workloads -regionabbr-prd

Network Security Groups

The section below outlines the Network Security Groups (NSGs) applied within the Azure Virtual Network for the i-ARM solution. These NSGs play a key role in enhancing security by managing inbound and outbound traffic at the subnet and VM level, minimizing unauthorized access risks. They contribute to optimized performance by filtering unnecessary traffic, enable tailored security rules for different resources, and promote a clear network structure by logically organizing security boundaries. For detailed NSG configurations, please refer to the section below.

Name	Inbound/ Outbound	Rule Name	Port/ Protocol	Priority	Source	Destination	Action	Description
nsg-iarm-webapp-regionabbr-prd	Inbound	AllowVnetInBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows traffic between resources within the same virtual network.
Inbound	AllowAzureLoadBalancerInBound	Any	65001	AzureLoadBalancer	Any	Allow	Allows traffic from the Azure load balancer to the resources.
Inbound	DenyAllInBound	Any	65500	Any	Any	Deny	Denies all inbound traffic by default.
Outbound	AllowVnetOutBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows outbound traffic between resources within the same virtual network.
Outbound	AllowInternetOutBound	Any	65001	Any	Internet	Allow	Allows outbound traffic to the internet.
Outbound	DenyAllOutBound	Any	65500	Any	Any	Deny	Denies all outbound traffic by default.

Name	Inbound/ Outbound	Rule Name	Port/ Protocol	Priority	Source	Destination	Action	Description
nsg-iarm-funcapp-regionabbr-prd	Inbound	AllowVnetInBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows traffic between resources within the same virtual network.
Inbound	AllowAzureLoadBalancerInBound	Any	65001	AzureLoadBalancer	Any	Allow	Allows traffic from the Azure load balancer to the resources.
Inbound	DenyAllInBound	Any	65500	Any	Any	Deny	Denies all inbound traffic by default.
Outbound	AllowVnetOutBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows outbound traffic between resources within the same virtual network.
Outbound	AllowInternetOutBound	Any	65001	Any	Internet	Allow	Allows outbound traffic to the internet.
Outbound	DenyAllOutBound	Any	65500	Any	Any	Deny	Denies all outbound traffic by default.

Name	Inbound/ Outbound	Rule Name	Port/ Protocol	Priority	Source	Destination	Action	Description
nsg-iarm-pe-regionabbr-prd	Inbound	AllowVnetInBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows traffic between resources within the same virtual network.
Inbound	AllowAzureLoadBalancerInBound	Any	65001	AzureLoadBalancer	Any	Allow	Allows traffic from the Azure load balancer to the resources.
Inbound	DenyAllInBound	Any	65500	Any	Any	Deny	Denies all inbound traffic by default.
Outbound	AllowVnetOutBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows outbound traffic between resources within the same virtual network.
Outbound	AllowInternetOutBound	Any	65001	Any	Internet	Allow	Allows outbound traffic to the internet.
Outbound	DenyAllOutBound	Any	65500	Any	Any	Deny	Denies all outbound traffic by default.

Name	Inbound/ Outbound	Rule Name	Port/ Protocol	Priority	Source	Destination	Action	Description
nsg-iarm-workloads-regionabbr-prd	Inbound	AllowVnetInBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows traffic between resources within the same virtual network.
Inbound	AllowAzureLoadBalancerInBound	Any	65001	AzureLoadBalancer	Any	Allow	Allows traffic from the Azure load balancer to the resources.
Inbound	DenyAllInBound	Any	65500	Any	Any	Deny	Denies all inbound traffic by default.
Outbound	AllowVnetOutBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows outbound traffic between resources within the same virtual network.
Outbound	AllowInternetOutBound	Any	65001	Any	Internet	Allow	Allows outbound traffic to the internet.
Outbound	DenyAllOutBound	Any	65500	Any	Any	Deny	Denies all outbound traffic by default.

Name	Inbound/ Outbound	Rule Name	Port/ Protocol	Priority	Source	Destination	Action	Description
nsg-iarm-bastion-regionabbr-prd	Inbound	AllowHttpsInbound	443	120	Internet	Any	Allow	Allows inbound HTTPS traffic from the internet to any destination.
Inbound	AllowGatewayManagerInbound	443	130	GatewayManager	Any	Allow	Allows inbound traffic from the Gateway Manager on port 443 to any destination.
Inbound	AllowAzureLoadBalancerInbound	443	140	AzureLoadBalancer	Any	Allow	Allows inbound traffic from the Azure Load Balancer on port 443 to any destination.
Inbound	AllowBastionHostCommunication8080	8080	150	VirtualNetwork	VirtualNetwork	Allow	Allows communication between resources within the virtual network on port 8080.
Inbound	AllowBastionHostCommunication5701	8080	151	VirtualNetwork	VirtualNetwork	Allow	Allows communication between resources within the virtual network on port 8080.
Inbound	AllowVnetInBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows traffic between resources within the same virtual network.
Inbound	AllowAzureLoadBalancerInBound	Any	65001	AzureLoadBalancer	Any	Allow	Allows traffic from the Azure load balancer to the resources.
Inbound	DenyAllInBound	Any	65500	Any	Any	Deny	Denies all inbound traffic by default.
Outbound	AllowSshOutbound	22	100	Any	VirtualNetwork	Allow	Allows outbound SSH traffic on port 22 to the virtual network.
Outbound	AllowRdpOutbound	3389	101	Any	VirtualNetwork	Allow	Allows outbound RDP traffic on port 3389 to the virtual network.
Outbound	AllowAzureCloudOutbound	443	110	Any	AzureCloud	Allow	Allows outbound HTTPS traffic on port 443 to Azure Cloud services.
Outbound	AllowBastionCommunication8080	8080	120	VirtualNetwork	VirtualNetwork	Allow	Allows outbound communication on port 8080 within the virtual network.
Outbound	AllowBastionCommunication5701	5701	121	VirtualNetwork	VirtualNetwork	Allow	Allows outbound communication on port 5701 within the virtual network.
Outbound	AllowHttpOutbound	80	130	Any	Internet	Allow	Allows outbound HTTP traffic on port 80 to the internet.
Outbound	AllowVnetOutBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows outbound traffic between resources within the same virtual network.
Outbound	AllowInternetOutBound	Any	65001	Any	Internet	Allow	Allows outbound traffic to the internet.
Outbound	DenyAllOutBound	Any	65500	Any	Any	Deny	Denies all outbound traffic by default.

Name	Inbound/ Outbound	Rule Name	Port/ Protocol	Priority	Source	Destination	Action	Description
nsg-iarm-container-regionabbr-prd	Inbound	AllowVnetInBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows traffic between resources within the same virtual network.
Inbound	AllowAzureLoadBalancerInBound	Any	65001	AzureLoadBalancer	Any	Allow	Allows traffic from the Azure load balancer to the resources.
Inbound	DenyAllInBound	Any	65500	Any	Any	Deny	Denies all inbound traffic by default.
Outbound	AllowVnetOutBound	Any	65000	VirtualNetwork	VirtualNetwork	Allow	Allows outbound traffic between resources within the same virtual network.
Outbound	AllowInternetOutBound	Any	65001	Any	Internet	Allow	Allows outbound traffic to the internet.
Outbound	DenyAllOutBound	Any	65500	Any	Any	Deny	Denies all outbound traffic by default.

Subnets

The section below details the subnets within the Azure Virtual Network for the i-ARM solution. This isolation is critical for improving security by containing network traffic and reducing unauthorized access risks, optimizing performance through effective bandwidth management, allowing for personalized application of network security group rules, and improving clarity by logically segmenting resources. For specific subnet configurations, please refer to the section below.

Name	vNet	Address Space	Route Table	NSG	Description
subnet-iarm-webapp-regionabbr-prd	vnet-iarm-svc-regionabbr-prd	x.x.x.x/25	Default	nsg-iarm-webapp-regionabbr-prd	This subnet provides a secure and scalable environment for hosting web applications.
subnet-iarm-funcapp-regionabbr-prd	vnet-iarm-svc-regionabbr-prd	x.x.x.x /25	Default	nsg-iarm-funcapp-regionabbr-prd	This subnet ensures that serverless functions operate within a secure and isolated environment.
subnet-iarm-pe-regionabbr-prd	vnet-iarm-svc-regionabbr-prd	x.x.x.x /25	Default	nsg-iarm-pe-regionabbr-prd	This subnet secures private access to Azure services, ensuring that sensitive data is exchanged without being exposed to the public internet.
subnet-iarm-workloads-regionabbr-prd	vnet-iarm-svc-regionabbr-prd	x.x.x.x /25	Default	nsg-iarm-workloads-regionabbr-prd	This subnet isolates and secures virtual machines, enabling controlled access to VMs.
AzureBastionSubnet	vnet-iarm-svc-regionabbr-prd	x.x.x.x /25	Default	nsg-iarm-bastion-regionabbr-prd	The Bastion subnet enables secure remote access to Azure Virtual Machines (VMs) without exposing them to the public internet. Learn more
subnet-iarm-container-regionabbr-prd	vnet-iarm-svc-regionabbr-prd	x.x.x.x /25	Default	nsg-iarm-container-regionabbr-prd	This subnet enhances the network capabilities and security of container instances in Azure.

Key Vault

Vault

Azure Key Vault is a critical component for the i-ARM solution, safeguarding secrets used by services within the i-ARM framework. It provides secure storage for sensitive data such as API keys, passwords, ensuring that they are protected with strong encryption and access policies. Integrated with Entra ID / Azure Active Directory, it enforces strict access controls, allowing only authorized users and applications to retrieve sensitive information.

• Only one key vault is required. All secrets and certificates will be stored in this key vault.

Note: The key vault should have the IP addresses of the Power platform to be whitelisted. These IP addresses vary depending on the region where the power platform is hosted.

Reference: Power Platform Outbound IP Addresses

Name	kv-iarm-svc-regionabbr-prd
Description	Required to securely store and access secrets, certificates, API keys. Access is tightly controlled.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	UK-SOUTH
Tier	Standard
Access Configuration (Permission Model)	Azure role-based access control (RBAC)
Resource Access	Not required
Network Access	Enabled from selected virtual networks and IP addresses*
Private Endpoint	Name	kv-iarm-svc-regionabbr-prd-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.vaultcore.azure.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

* An azure policy exemption rule needs to be created in the consumer azure portal to exempt the “kv-iarm-svc-regionabbr-prd” key vault from the “Deny-PublicPaaSEndpoints” policy to allow configuring the Key Vault firewall with “Enabled from selected virtual networks and IP addresses”. This is necessary for Power Automate to read secrets from the “kv-iarm-svc-regionabbr-prd” Key Vault. Since Power Automate is a cloud service, it initiates requests from the public internet and does not operate within the same private network as the key vault.

Web

App Service Plan

This section outlines the configurations for the App Service Plan associated with the i-ARM web app and the different Azure Function Apps, all of which are VNET integrated.

The App Service Plan for the i-ARM web app ensures a scalable and high-availability hosting environment with integrated security features and monitoring tools, while the Azure Function Apps are designed to efficiently handle serverless workloads with custom scaling options.

Name	asp-iarm-ui-regionabbr-prd
Description	This app service is used to create and manage the compute resources required by the i-ARM web app supporting the user experience.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-webapp-regionabbr-prd

Name	asp-iarm-urc-regionabbr-prd
Description	This app service hosts the compute resources required to synchronize retention labels from Microsoft Purview to i-ARM database.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-funcapp-regionabbr-prd

Name	asp-iarm-mydisp-regionabbr-prd
Description	This app service hosts the compute resources required for the business layer of the disposal dashboard and related workflows supporting the i-ARM webapp. This app service provides integration between the i-ARM web app and the i-ARM database.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-funcapp-regionabbr-prd

Name	asp-iarm-mydata-regionabbr-prd
Description	This app service hosts the compute resources required for the business layer of the mydata supporting navigation and administration modules in the i-ARM webapp. This app service provides integration between the i-ARM web app and the i-ARM database.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-funcapp-regionabbr-prd

Name	asp-iarm-prmbulk-regionabbr-prd
Description	This app service hosts the compute resources required for the bulk import functionality supporting the PRM module.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-funcapp-regionabbr-prd

Name	asp-iarm-prmsync-regionabbr-prd
Description	This app service hosts the compute resources required for the sync functionality supporting the PRM module.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-funcapp-regionabbr-prd

Name	asp-iarm-m365auditsync-regionabbr-prd
Description	This app service hosts the compute resources required for the M365 audit logs sync functionality to i-ARM Data Store.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-webapp-regionabbr-prd

Name	asp-iarm-m365auditconnector-regionabbr-prd
Description	This app service hosts the compute resources required for the M365 audit logs connector sync functionality to i-ARM Data Store.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-funcapp-regionabbr-prd

Name	asp-iarm-m365dispconnector-regionabbr-prd
Description	This app service hosts the compute resources required for the M365 disposal connector sync functionality to i-ARM Data Store.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Operating System	Windows
Pricing Plan	Standard S2
Subnet	subnet-iarm-funcapp-regionabbr-prd

Function App

This section details the configurations for the Azure Function Apps, which are integrated with private endpoints and deployed within a designated private subnet (Private Endpoint - PE subnet). The use of private endpoints ensures secure, private access to the Function Apps, enhancing data protection and compliance by preventing exposure to the public internet.

Name	func-iarm-urc-regionabbr-prd
Description	This function app is associated with the app service “asp-iarm-urc-regionabbr-prd”. The purpose of this function app is to provide the logic for synchronizing the retention labels from MS Purview to i-ARM database.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Deploy Type	Code;.NET; 8.0 Isolated
Operating System	Windows
Hosting	App Service Plan (asp-iarm-urc-regionabbr-prd)
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insights	appi-iarm-urc-regionabbr-prd
Private Endpoint	Name	{function app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	func-iarm-mydisp-regionabbr-prd
Description	This function app is associated with the app service “asp-iarm-mydisp-regionabbr-prd”. This function app provides the logic for the workflows associated with the disposition process.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Deploy Type	Code;.NET; 8.0 Isolated
Operating System	Windows
Hosting	App Service Plan (asp-iarm-mydisp-regionabbr-prd)
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-mydisp-regionabbr-prd
Private Endpoint	Name	{function app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	func-iarm-mydata-regionabbr-prd
Description	This function app is associated with the app service “asp-iarm-mydata-regionabbr-prd”. This function app provides the logic for the navigation and administration module process.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Deploy Type	Code;.NET; 8.0 Isolated
Operating System	Windows
Hosting	App Service Plan ( asp-iarm-mydata-regionabbr-prd)
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-mydata-regionabbr-prd
Private Endpoint	Name	{function app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	func-iarm-prmbulk-regionabbr-prd
Description	This function app is associated with the app service “asp-iarm-prmbulk-regionabbr-prd ”. This durable function app provides the logic for the bulk import functionality associated with the PRM bulk import process.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Deploy Type	Code;.NET; 8.0 Isolated
Operating System	Windows
Hosting	App Service Plan ( asp-iarm-prmbulk-regionabbr-prd)
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-prmbulk-regionabbr-prd
Private Endpoint	Name	{function app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	func-iarm-prmsync-regionabbr-prd
Description	This function app is associated with the app service “asp-iarm-prmsync-regionabbr-prd ”. This function app provides the logic for the sync functionality associated with the PRM sync process.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Deploy Type	Code;.NET; 8.0 Isolated
Operating System	Windows
Hosting	App Service Plan ( asp-iarm-prmsync-regionabbr-prd)
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-prmsync-regionabbr-prd
Private Endpoint	Name	{function app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	func-iarm-m365auditconnector-regionabbr-prd
Description	This function app is associated with the app service “asp-iarm-m365auditconnector-regionabbr-prd”. This function app provides the logic for the fetching and performing data transformation of the m365 audit sync data captured.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Deploy Type	Code;.NET; 8.0 Isolated
Operating System	Windows
Hosting	App Service Plan (asp-iarm-m365auditconnector-regionabbr-prd )
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-m365auditconnector-regionabbr-prd
Private Endpoint	Name	{function app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	func-iarm-m365dispconnector-regionabbr-prd
Description	This function app is associated with the app service “ asp-iarm-m365dispconnector-regionabbr-prd”. This function app provides the logic for the fetching and performing data transformation of the m365 audit sync data captured.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Deploy Type	Code;.NET; 8.0 Isolated
Operating System	Windows
Hosting	App Service Plan (asp-iarm-m365auditconnector-regionabbr-prd )
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-m365dispconnector-regionabbr-prd
Private Endpoint	Name	{function app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Storage Accounts

This section outlines the configurations for the Azure Storage Accounts associated with the Function Apps. Storage accounts are integrated with private endpoints and are deployed within the same private subnet (Private Endpoint - PE subnet). By utilizing private endpoints, the storage accounts benefit from secure and private connectivity, ensuring that data is transmitted only within the private network and remains isolated from the public internet. This setup enhances security and compliance by safeguarding the storage accounts from unauthorized access while supporting the seamless operation of the Function Apps.

Name	saiarmmydataregionabbrprd
Description	This storage account is associated with the ‘func-iarm-mydata-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarmmydispregionabbrprd
Description	This storage account is associated with the ‘func-iarm-mydisp-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarmurcregionabbrprd
Description	This storage account is associated with the ‘func-iarm-urc-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarmprmbulkregionabbrprd
Description	This storage account is associated with the ‘func-iarm-prmbulk-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Private Endpoint	Name	{storage account name}-blob-pe {storage account name}-queue-pe {storage account name}-table-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net privatelink.queue.core.windows.net privatelink.table.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarmprmsyncregionabbrprd
Description	This storage account is associated with the ‘func-iarm-prmsync-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarm365syncregionabbrprd
Description	This storage account is associated with the app service ‘wj-iarm-m365auditsync-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Data Storage[ Queue]	queue-iarm-m365auditfullscantrigger-regionabbr-prd
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net privatelink.queue.core.windows.net privatelink.table.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarm365connregionabbrprd
Description	This storage account is associated with the ‘func-iarm-m365auditconnector-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net privatelink.queue.core.windows.net privatelink.table.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarmdispconregionabbrprd
Description	This storage account is associated with the ‘func-iarm-m365dispconnector-regionabbr-prd‘ function app.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net privatelink.queue.core.windows.net privatelink.table.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarmarchiveregionabbrprd
Description	This storage account is used for storing the SharePoint content that is approved for archival from my disposal dashboard review screen
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	RA-GZRS
Network access	Enabled from selected virtual networks and IP addresses*
Data Storage[ Container]	container-iarm-archived-files-regionabbr-prd
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	saiarmdiappuksothprd
Description	This storage account is used for downloading source instance registration templates & storing source instance registration files.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Performance	Standard (General Purpose V2)
Redundancy	ZRS
Network access	Disable Public Access
Data Storage[ Container]	container-iarm-manifest-files-regionabbr-prd container-iarm-manifest-templates-regionabbr-prd
Private Endpoint	Name	{storage account name}-blob-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.blob.core.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

* An azure policy exemption rule needs to be created in the consumer azure portal to exempt the “saiarmarchiveregionabbrprd” storage account from the “Deny-PublicPaaSEndpoints” policy to allow configuring the Storage account firewall with “Enabled from selected virtual networks and IP addresses”. This is necessary for Power Automate to create blobs within the “saiarmarchiveregionabbrprd” storage account. Since Power Automate is a cloud service, it initiates requests from the public internet and does not operate within the same private network as the storage account.

App Service

This section outlines the App Service configuration for the i-ARM web app, which includes a private endpoint integrated within a designated private subnet (PE subnet). The private endpoint ensures secure, private access to the web app, significantly enhancing data security by restricting exposure to the public internet.

Name	web-iarm-ui-regionabbr-prd (User Interface)
Description	This app service is associated with the App service plan “asp-iarm-ui-regionabbr-prd”. The purpose of this is to provide logic for the User interface related to all of the i-ARM portal features.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Publish	Code; Node 18 LTS; Windows
Hosting	App Service Plan ( asp-iarm-ui-regionabbr-prd)
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-ui-regionabbr-prd
Private Endpoint	Name	{web app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	wj-iarm-m365auditsync-regionabbr-prd
Description	This app service is associated with the App service plan “asp-iarm-m365auditsync-regionabbr-prd”. The purpose of this is to provide logic for syncing M365 audit log records to i-ARM Datastore.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Publish	Code:.NET; 8.0 Isolated
Hosting	App Service Plan (asp-iarm-m365auditsync-regionabbr-prd)
Managed Identity	Enabled (System Assigned)
Network access	Disable Public Access
Network Injection	Enabled; vnet-iarm-regionabbr-prd (app)
Application Insight	appi-iarm-m365auditsync-regionabbr-prd
Private Endpoint	Name	{web app name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.azurewebsites.net
Continuous deployment	Disabled
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Database

Azure SQL Database

This section details the configuration of the Azure SQL Database, which serves as the backend data store for i-ARM services. The database is equipped with a private endpoint, ensuring secure, private access within a designated VNET and preventing exposure to the public internet.

Using the General-Purpose tier, it offers balanced performance and cost-efficiency for standard workloads. Native data encryption is enabled, providing an additional layer of security for sensitive information, while Azure's built-in firewall ensures that only authorized access is permitted.

This setup delivers a strong and secure data storage solution, integral to the reliable operation of i-ARM services.

Name	sql-iarm-svc-regionabbr-prd
Description	This is the database which holds all the data managed by i-ARM across all its functionalities.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Service + Compute Tier	General Purpose, Provisioned, 2 vCores. (The number of cores can be scaled up based on the workload demand)
Workload Environment	Production
Database Zone Redundant	Yes
Backup Redundancy	GZRS
Auth Method	Microsoft Entra authentication, SQL authentication
Admin	sg-svc-iarm-sqlentraadministrators-prd
Managed Identity	Enabled (System Assigned)
Public Endpoint	Disabled
Private Endpoint	Name	{sql server name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.database.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Name	sql-iarmmpip-svc-regionabbr-prd
Description	This is the database which holds all the configuration data related to MPIP Scanner
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Service + Compute Tier	General Purpose, Provisioned, 2 vCores. (The number of cores can be scaled up based on the workload demand)
Workload Environment	Production
Database Zone Redundant	Yes
Backup Redundancy	GZRS
Auth Method	Microsoft Entra authentication, SQL authentication
Admin	sg-svc-iarm-sqlentraadministrators-prd
Managed Identity	Enabled (System Assigned)
Public Endpoint	Disabled
Private Endpoint	Name	{sql server name}-pe
Subnet	subnet-iarm-pe-regionabbr-prd
Private DNS Zone	privatelink.database.windows.net
Diagnostics	Diagnostics logs are sent to the central log analytics workspace of the solution

Azure Monitoring

Log Analytics Workspace

This section provides an overview of the Log Analytics Workspace configuration, which acts as a central repository for aggregating and analyzing log data from various resources of i-ARM. The workspace is crucial for enhancing operational visibility and security by enabling the collection, querying, and monitoring of log data, while supporting advanced integrations with services like Azure Monitor and Azure Sentinel for comprehensive data analysis and threat detection, if required.

Name	log-iarm-svc-regionabbr-prd
Description	This workspace acts as a central repository for all the diagnostics logs
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>

Virtual Machine

On-Premises Data Gateway

The application gateway serves as an intermediary, facilitating secure connections between external SaaS offerings, such as Power Platform and Power BI, and the SQL database that is safeguarded by a firewall or positioned behind the native platform firewall of SQL azure database.

Note:

• If IP Whitelisting can be configured on the Azure SQL server, then there is no need for the data gateway.
• The VM requires an interactive logon, this can be done using a local account for a one-off configuration of data gateway on the VM.
• Based on the workload, additional VMs may need to be configured to function as data gateways
• SQL connection using Data Gateway works only with either SQL Authentication or Windows Authentication
• Internet should be enabled on the Data gateway VM
• Data gateway is a manual installation by downloading MSI package from Microsoft website. Detailed steps for installation can be found here - Install an on-premises data gateway | Microsoft Learn
• The Data Gateway VM should not have any Azure policy such as Auto Shutdown Schedule configured for automatic shutdown that would cause it to shut down on its own. Reference: Deploy Virtual Machine Auto Shutdown Schedule - Deploy-Vm-autoShutdown

VM Name	vmiarmdgukprd
Description	The gateway provides connectivity between MS Purview Power automate flows, Power BI and i-ARM database. The gateway supports the registration of records eligible for disposal between MS Purview and i-ARM.
Resource Group	rg-iarm-svc-regionabbr-prd
Location	<Consumer Azure region>
VM Size	General Purpose D4ds_v4
Operating System	Windows Server 2022
Subnet	subnet-iarm-workloads-regionabbr-prd
Public IP	Yes (if required for external access)
Installation Requirements	On-premises Data Gateway, .NET Framework 4.7 or later

i-ARM Scanner Services

The virtual machine is where the i-ARM Scanner Services will be installed. The scanner service captures the file properties and other information related to the source being scanned into the i-ARM Data Store. Infotechtion recommends a minimum of 2 Virtual Machines to host the i-ARM and MPIP Scanner Agents respectively.

VM Name	vmiarmscannerservice01prd, vmiarmscannerservice02prd
Description	The scanner service will scan the mounted & configured Network File Shares or Azure File Shares.
Resource Group	rg-iarm-svc-regionabbr-prd
Location	<Consumer Azure region>
VM Size	Standard_D8as_v4 (8 vcpus, 32 GiB memory)
Operating System	Windows Server 2022
Subnet	subnet-iarm-workloads-regionabbr-prd
Public IP	Yes (if required for external access)
Installation Requirements	.NET Framework 4.7 or later, .Net Core 8.0, Information Protection Scanner

Note:

• IP Whitelisting needs to be configured on the Azure KeyVault.
• The VM needs to be part of the domain and will require login from a Service Account.
• The VM should be able to communicate with the File Shares to scan an i-ARM Data Store to capture the metadata information for part of the same network as the Network File Share and
• the scanner Service Account needs Read/Write access to the Network File Share (Write only in case the Immutability feature is required)
• Incase Scanner Service is configured to scan Azure File Share, then mounting of Azure File Share has to be using Shared Access Key.
• The VM needs will require a Certificate to be installed to access the Key Vault. A certificate can either be procured from your Certificate Authority or a Self-Signed generated Certificate will also work.
• Based on the workload, additional VMs may need to be configured to scan larger number of data sources
• Internet should be enabled on the i-ARM Scanner Service VM
• If the Windows Defender service is configured to scan the NFS Agent Service folder, it should be exempted to avoid performance issues.
• Additionally, we recommend stopping the NFS Agent Service, as it has been observed to consume high CPU resources. This consumption can eventually increase runtime and decrease overall performance.
• To support scans on NFS shares, services for NFS must be deployed on the scanner machine.

On your machine, navigate to the Windows Features (Turn Windows features on or off) settings dialog, and select the following items: Services for NFS > Administrative Tools and Client for NFS.

• When the scanner is installed on a Windows server machine, you must also install the Microsoft Office iFilter in order to scan .zip files for sensitive information types.
• The i-ARM Scanner Service VM should not have any Azure policy such as Auto Shutdown Schedule configured for automatic shutdown that would cause it to shut down on its own. Reference: Deploy Virtual Machine Auto Shutdown Schedule - Deploy-Vm-autoShutdown
• MPIP Scanner Reference: Get started with the information protection scanner | Microsoft Learn

Security

Consumer Firewall Access

The policy document shared earlier outlines (Azure policies) various security policies established as part of the Enterprise Scale Landing Zone. These policies are designed to enhance the overall security posture of the subscription, ensuring robust protection against potential threats. As a critical component of our architecture, the i-ARM services are required to comply with these security policies, reinforcing our commitment to safeguarding data and maintaining regulatory compliance.

Note: additional firewall policies should be updated by the consumer cloud support team for review by the Infotechtion engagement team dedicated to the consumer.

The table below outlines the rules to be added in the connectivity subscription’s azure firewall

#	Rule Name Justification	Source	Destination	Ports	Protocol	Action
1	ALLOW_PE_TRAFFIC Used for allowing traffic from the connectivity subscription to the private endpoints of the i-ARM subscription within the PE subnet	HUB_VNET_ADDRESS_SPACESubscription: Connectivity Subscription	I-ARM_PE_SUBNET (subnet-iarm-pe-regionabbr-prd)Subscription: i-ARM Subscription	443	TCP	ALLOW
2	ALLOW_IARM_WEBAPP_OUTBOUND Used by i-ARM Web App to make Graph API calls for user authentication, establish connections with storage accounts, log into Application Insights, and integrate with SharePoint	I-ARM_WEBAPP_SUBNET (subnet-iarm-webapp-regionabbr-prd)Subscription: i-ARM Subscription	dc.applicationinsights.azure.comdc.applicationinsights.microsoft.comdc.services.visualstudio.com*.in.applicationinsights.azure.comlive.applicationinsights.azure.comrt.applicationinsights.microsoft.comrt.services.visualstudio.com*.ods.opinsights.azure.com*.oms.opinsights.azure.com*.blob.core.windows.netgraph.microsoft.com/**.sharepoint.com manage.office.com/api/**.database.windows.net*.queue.core.windows.net *.blob.core.windows.net*.table.core.windows.net *.vault.azure.net	443	TCP	ALLOW
3	ALLOW_IARM_FUNCAPP_OUTBOUND Used by i-ARM Function Apps to make Graph API calls, establish connections with storage accounts, log into Application Insights, and integrate with SharePoint	I-ARM_FUNCTIONAPP_SUBNET (subnet-iarm-funcapp-regionabbr-prd)Subscription: i-ARM Subscription	dc.applicationinsights.azure.comdc.applicationinsights.microsoft.comdc.services.visualstudio.com*.in.applicationinsights.azure.comlive.applicationinsights.azure.comrt.applicationinsights.microsoft.comrt.services.visualstudio.com*.ods.opinsights.azure.com*.oms.opinsights.azure.com*.blob.core.windows.netgraph.microsoft.com/**.sharepoint.com manage.office.com/api/**.database.windows.net*.queue.core.windows.net *.blob.core.windows.net*.table.core.windows.net *.vault.azure.net	443	TCP	ALLOW
4	ALLOW_IARM_WEBAPP_OUTBOUND_SQL Used to facilitate communication between i-ARM Web App and i-ARM datastore	I-ARM_WEBAPP_SUBNET (subnet-iarm-webapp-regionabbr-prd)Subscription: i-ARM Subscription	*.database.windows.net	1433	TCP	ALLOW
5	ALLOW_IARM_FUNCAPP_OUTBOUND_SQL Used to facilitate communication between i-ARM Function Apps and i-ARM datastore	I-ARM_FUNCTIONAPP_SUBNET (subnet-iarm-funcapp-regionabbr-prd)Subscription: i-ARM Subscription	*.database.windows.net	1433	TCP	ALLOW
6	ALLOW_IARM_WORKLOAD_OUTBOUND Used for Advanced Message Queuing Protocol (AMQP)	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)Subscription: i-ARM Subscription	*.servicebus.window.net	5671-5672	TCP	ALLOW
7	ALLOW_IARM_WORKLOAD_OUTBOUND Used to download the installer. The gateway app also uses this domain to check the version and gateway region	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)	*.download.microsoft.com*.msftncsi.com	80	TCP	ALLOW
8	ALLOW_IARM_WORKLOAD_OUTBOUND Used to authenticate the gateway app for Microsoft Entra ID and OAuth2. Note that additional URLs could be required as part of the Microsoft Entra ID sign in process that can be unique to a tenant	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)Subscription: i-ARM Subscription	*.powerbi.com,*.analysis.windows.net*.login.windows.net, login.live.com, aadcdn.msauth.net, *.servicebus.windows.net,*.dc.services.visualstudio.com,*.frontend.clouddatahub.net,login.microsoft.com,login.windows.net,login.microsoftonline.com,*.microsoftonline-p.comgraph.microsoft.com/* *.sharepoint.com	443	TCP	ALLOW
9	ALLOW_IARM_WORKLOAD_OUTBOUND Listens on Azure Relay over TCP	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)Subscription: i-ARM Subscription	*.servicebus.windows.net	9350-9354	TCP	ALLOW
10	ALLOW_IARM_WORKLOAD_OUTBOUND Used to allow Internet access inside the Virtual machine	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)Subscription: i-ARM Subscription	*	80, 443	TCP	ALLOW
	ALLOW_IARM_WORKLOAD_OUTBOUND Used for MPIP Scanner Services	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)Subscription: i-ARM Subscription	*.aadrm.com*.azurerms.com*.informationprotection.azure.cominformationprotection.hosting.portal.azure.net*.aria.microsoft.com*.protection.outlook.com	443	TCP	ALLOW
	ALLOW_IARM_WORKLOAD_OUTBOUND Allows traffic for the agent installed on Azure VM to interact with the NFS and AFS	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)Subscription: i-ARM Subscription	NFS/ AFS	445	TCP	ALLOW
11	ALLOW_IARMPBI_TRAFFIC Used by Power BI to read data from i-ARM datastore	PowerBI (Azure Service Tag*)	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd) I-ARM_PE_SUBNET (subnet-iarm-pe-regionabbr-prd)Subscription: i-ARM Subscription	1433, 3342	TCP	ALLOW
12	ALLOW_IARMPA_TRAFFIC Used to facilitate communication between Power Automate and i-ARM datastore	AzureConnectors.UKSouth (Azure Service Tag*)AzureConnectors.UKSouth2 (Azure Service Tag*)	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd) I-ARM_PE_SUBNET (subnet-iarm-pe-regionabbr-prd)Subscription: i-ARM Subscription	1433, 443	TCP	ALLOW
13	ALLOW_RDP_OUTBOUND_BASTION Used to establish a remote session with the Data Gateway Virtual machine via bastion	I-ARM_BASTION_SUBNET (AzureBastionSubnet)Subscription: i-ARM Subscription	I-ARM_WORKLOAD_SUBNET (subnet-iarm-workloads-regionabbr-prd)Subscription: i-ARM Subscription	3389,22	TCP	ALLOW
14	ALLOW_IARMDEVOPS_TRAFFIC Used for provisioning and configuring i-ARM components and binaries deployment within i-ARM subscriptions resource group	AzureDevOps (Azure Service Tag)	I-ARM_VNET (vnet-iarm-svc-regionabbr-prd)Subscription: i-ARM Subscription	443	TCP	ALLOW
15	ALLOW_IARMACR_TRAFFIC Used for fetching windows images from Azure Container Registry hosted in Infotechtion Managed Subscription	MicrosoftContainerRegistry (Azure Service Tag) AzureFrontDoor.FirstParty (Azure Service Tag)	I-ARM_VNET (vnet-iarm-svc-regionabbr-prd) Subscription: i-ARM Subscription	443	TCP	ALLOW

*A service tag represents a group of IP address prefixes from a given Azure service. Microsoft manages the address prefixes encompassed by the service tag and automatically updates the service tag as addresses change, minimizing the complexity of frequent updates to network security rules. This service tag needs to be updated based on the consumer azure region.

Available Service Tags

Powerplatform

Power BI

This section provides an overview of the Power BI configuration, which acts as a central hub for aggregating and visualizing data from various resources of i-ARM. Power BI is crucial for enhancing operational insights and decision-making by enabling the creation of interactive reports and dashboards, while supporting advanced integrations for comprehensive data analysis and real-time performance monitoring, if required.

Workspace Name	iarm-pbi-workspace-prd
Description	The Power BI workspace where i-arm datasets, reports, and dashboards are stored.
Licensing	Pro/Premium*

Note:

* If the Power BI workspace is created with Premium Capacity, then users who only need to consume content (e.g., view reports and dashboards) do not require a Pro license. However, users who create, modify, or publish content in the workspace still need a Pro license

Power automate

This section provides an overview of the Power Automate configuration, which acts as the backbone for automating and orchestrating workflows supporting the disposal dashboard scenarios in i-ARM. Power Automate is crucial for streamlining operational processes by enabling automated flows that integrate various systems, trigger actions based on predefined conditions and ensure data consistency across platforms.

Power platform Environment	Default
Description	Environment hosts, manages, and segregates resources, applications, data, flows, and connections related to Power Automate
Type	Production
Dataverse	Yes
Premium Connectors used	Microsoft 365 Compliance, Azure Key Vault, Microsoft Dataverse, SQL Server, HTTP

Note:

When the power automate flows are imported in an environment other than the default power platform environment, then the labels should be created and managed using PowerShell only.

Learn more

SharePoint Webpart

PRM SPFx

The Physical Records Management Module within i-ARM is built on the SharePoint Framework (SPFx), that allow authorized users to register, categorize, and store information about physical records in a structured and secure manner. The modular design enables seamless integration with SharePoint’s core functionalities, ensuring that users can easily interact with their data while benefiting from features like version control, metadata tagging, and user permissions.

Display Name	Infotechtion PRM
Description	This webpart provides modern, user-friendly interface for registering and managing physical records.
Version	1

PnP Search SPFx

PnP (Patterns and Practices) Search in SPFx to enable a wide range of reporting scenarios. This allows users to dynamically search, filter, and generate customized reports on physical records based on various criteria, offering a flexible and powerful solution for managing records data.

Display Name	PnP Modern Search - Search Web Parts - v4
Description	This webpart provides enhanced search and filtering capabilities
Version	1.0.0.15

Modern Script Editor SPFx

The Physical Records Management Module within i-ARM leverages the modern Script Editor web part to support custom styling for an enhanced user experience.

Name	Modern Script Editor
Description	This webpart provides the capability to hide the OOTB page fields for better user interface.
Version	4.4.1.0

SharePoint Configuration

Note: A separate step by step document will be shared by the product team to perform the below configurations.

Content Type

Content Types are essential for defining the structure and metadata associated with physical records. A content type allows us to standardize the data fields used for specific categories of physical records within the system.

Term Store

The Term Store allows us to manage and maintain a consistent set of terms and metadata ensuring uniformity in categorization of physical records.

Search configuration

Managed properties are used to optimize the search for physical records by mapping relevant metadata fields so that these fields can be easily queried and retrieved via the search functionality. The PnP Search Webpart leverages these fields to allow authorized users to view reports based on the search and filter criteria.

Azure DevOps

Repository

The Infotechtion Azure DevOps code repository utilizes Git for version control, enabling collaboration through branching, pull requests, and code reviews. Integrated with Azure Pipelines for CI/CD, it automates builds and deployments while enforcing role-based access controls to ensure security and accountability in the i-ARM services development process.

Organization	Infotechtion
Project Name	i-ARM Infrastructure DevOps
Repo Name	iac-iarm

Note:

During CI/CD pipeline deployments, the IPs of the Microsoft-hosted agents running the deployment jobs must be whitelisted to ensure successful deployments. It is essential that the consumer tenant allows for this IP whitelisting.

All deployments in the consumer tenant for provisioning i-ARM resources will be managed exclusively through Bicep templates from Infotechtion's Azure DevOps. Additionally, Azure CLI commands will be utilized for configuring Container Registry and Container Instance activities. Deployments for the Azure Web App, Function App, and Web Job will also be managed from the same DevOps environment.

Azure Container Registry

This section outlines the configuration for Azure Container Registry associated with the deployment for i-ARM resources.

Azure Container Registry is a service from Microsoft Azure that helps you store and manage your container images. It makes it easy to build and deploy these images securely and at scale.

Name	acriarmregionabbrprd
Description	Azure Container Registry is used for storing and managing container images that can be deployed with other Azure services.
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
Pricing Plan	Premium

Azure container instance

Azure Container Instances (ACI) allows you to run containers in the cloud without managing infrastructure, which can be used to deploy i-ARM applications.

Name	aci-iarm-regionabbr-prd
Description	Azure Container Instances (ACI) is a fully managed service that allows you to run containers directly on the Microsoft Azure cloud without needing to manage the underlying infrastructure
Resource Group	rg-iarm-svc-regionabbr-prd
Region	<Consumer Azure region>
SKU	Standard
Image Source	Azure Container Registry
Registry	acriarmregionabbrprd
Image	acriarmregionabbrprd.azurecr.io/azp-agent:windows
Image Tag	azp-agent:windows
OS Type	Windows
Size	2 core CPU, 6GB Memory
Subnet	subnet-iarm-container-regionabbr-prd

List of allowed IP addresses and domain URLs:

Azure DevOps IP and URL Allow List

For more information on configuring client firewall rules for Azure Container Registry, refer to the official documentation: Configure client firewall rules for MCR

For more information on configuring client firewall rules for Azure Container Registry, refer to the official documentation: Configure client firewall rules for MCR

For a list of allowed IP addresses and domain URLs, refer to the official documentation: Azure DevOps IP and URL Allow List

Binary validation

Binary validation helps ensure that only high-quality, secure, and correctly versioned binaries are built and released to customer environments. Binaries refer to files such as executables, libraries, or other compiled files, such as .dll and .js files

To ensure the integrity and security of our delivered packages, we perform checksum (SHA-256) validation on all binary files produced. During the build process in Infotechtion DevOps, a SHA-256 checksum is generated for each binary file and documented for reference. This check sum will be included in the release notes with a listing of each binary included in the package shared with the customer IT team to allow for independent validation.

Package Properties Includes:

Property	Description
File Name	The name of the binary file.
File Extension	The type of the file, indicating its format (e.g., .exe, .dll, .js).
File Creation Date	The date and time when the binary file was created
SHA256	The SHA-256 checksum generated during the build process, used for validation.

Validation Process for Customer IT Teams:

Once the package is deployed, the customer IT team can validate the binaries using a script provided by Infotechtion. This script generates a SHA-256 inventory of each binary deployed via the package.

To validate the binaries from the Azure resource side, follow the following steps:

Download the Deployment package

• Navigate to customer managed Azure portal.
• Go to i-ARM resource Group “rg-iarm-svc-regionabbr-prd”
• Navigate to each i-ARM resources listed below and download it to the local system. (Note: In the Landing Zone, please note that additional steps may be required for downloading. Ensure you have the necessary permissions to the resources)
  • Function Apps
  • Web Apps

Extract the Package

• The package would be compressed (e.g., in a .zip format), extracting the contents to a designated folder on the local system.

Run the SHA-256 Validation Script

• Open a terminal or command prompt on the local machine.
• Navigate to the directory where the extracted binaries are located.
• Execute the SHA-256 validation script provided by Infotechtion. This script will generate SHA-256 checksums for all binary files in the directory and compare them against the checksums listed in the release notes.

Validation

• Ensure that all checksums match the release notes shared.

• To be confirmed during configuration based on alignment with the consumer cloud support.
